For fountain pen points.
Atomic Number:76Atomic Symbol:Os
Atomic Weight:190.2Electron Configuration:2-8-18-32-14-2
Shells:2,8,18,32,14,2Filling Orbital:5d6
Melting Point:3045oCBoiling Point:5027oC
Description:Hard fine black powder or hard blue-gray mass.
Uses:Used to tip gold pen points,to make standard weights
and measures and electric light filaments.


(Gr. osme, a smell) Discovered in 1803 by Tennant in the residue left when crude platinum is dissolved by aqua regia.


  • Osmium occurs in iridosule and in platinum-bearing river sands of the Urals, North America, and South America.
  • It is also found in the nickel-bearing ores of Sudbury, Ontario region along with other platinum metals.
  • While the quantity of platinum metals in these ores is very small, the large tonnages of nickel ores processed make commercial recovery possible.


  • The metal is lustrous, bluish white, extremely hard, and brittle even at high temperatures.
  • It has the highest melting point and the lowest vapor pressure of the platinum group.
  • The metal is very difficult to fabricate, but the powdered or spongy metal slowly gives off osmium tetroxide, which as a powerful oxidizing agent and has a strong smell.
  • The tetroxide is highly toxic, and boils at 130C.


  • Concentrations in air as low as 10^7 g/m^3 can cause lung congestion, skin damage, or eye damage.
  • Exposure to osmium tetroxide should not exceed 0.0016 mg/m^3 (8-hour time weighted average - 40-hour work week).
  • The tetroxide has been used to detect fingerprints and to stain fatty tissue for miscroscope slides.
  • The metal is almost entirely used to produce very hard alloys, with other metals of the platinum group, for fountain pen tips, instrument pivots, phonograph needles, and electrical contacts.


The price of 99% pure osmium powder - the form usually supplied commercially - is about $100/g, depending on quantity and supplier.


  • The measured densities of iridium and osmium seem to indicate that osmium is slightly more dense than iridium, so osmium has generally been credited with being the heaviest known element.
  • Calculations of the density from the space lattice which may be more reliable for these elements than actual measurements, however, give a density of 22.65 for iridium compared to 22.661 for osmium.
  • At present, therefore, we know either iridium or osmium is the heaviest element, but the data do not allow selection between the two.
